Joymore-7A passes TUV elevator energy efficiency certification and obtains an A-level energy efficiency certificate.
Flexible layout.
Shaft utilization rate isup to 58.06%.
Simplifed design.
lnstallation efficiency improves by 30%.
| NO. | Specification | 400 | 450 | 550 | 630 | 800 | 1050 | |||||
| 1 | Capacity (kg) | 400 | 450 | 550 | 630 | 800 | 1050 | |||||
| 2 | Speed (m/s) | 1 | 1 | 1 | 1 | 1.75 | 1 | 1.75 | 1 | 1.75 | ||
| 3 | Operation System | full collective selection operation | ||||||||||
| 4 | Driving System | VVVF | ||||||||||
| 5 | Door Operator System | VVVF | ||||||||||
| 6 | Traction Machine | Permanent Magnet Synchronous Gearless type | ||||||||||
| 7 | Control System | CTRL80 | ||||||||||
| 8 | Parallel Elevators | 2 units | ||||||||||
| 9 | Group Control Elevators | 3-8 units | ||||||||||
| 10 | Wide Car1 | Car Dimension mm width*depth | 1000x1100 | 1000x1200 | 1000x1300 | 1100x1400 | 1350x1400 | 1500x1600 | ||||
| Single door shaft size(mm) W*H | 1620x1450 | 1620x1600 | 1620x1650 | 1750x1750 | 1970x1750 | 2130x1950 | ||||||
| Split door shaft size(mm) W*H | 1620x1610 | 1620x1710 | 1620x1810 | 1750x1910 | 1970x1910 | 2130x2110 | ||||||
| 11 | Wide Car2 | Car Dimension mm width*depth | - | 1400x900x2420 | 1400x1000 | 1400x1100 | 1100x1750 | 1100x2100 | ||||
| Shaft Size mm W*H | - | 2020x1300 | 2020x1400 | 2020x1550 | 1770x2100 | 1780x2450 | ||||||
